Part Number : B1642
Function : 60V, TRANSISTOR
Packatge : TO-220 Type
Maker : Toshiba
Image :
Description :
1. Low Collector Saturation Voltage
2. Collector Metal (Fin) is Fully Covered with Mold Resin.
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = - 60 V
2. Collector to Emitter Voltage : Vceo = - 60 V
3. Emitter to Base Voltage : Vebo = - 7 V
4. Collector Current : Ic = - 4A
5. Total Dissipation : Pc = 2 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Pinouts :
Applications
: AUDIO FREQUENCY POWER AMPLIFIER
Datasheet PDF Download :
Others datasheet of same file : 2SB1642
