Part Number : AQZ202D

Function : Power photoMOS relay (voltage sensitive type). AC/DC type. Solid State Relays

Package : PCB Mount 4 Pin Type

Maker : Panasonic Corporation

Pinouts :
AQZ202D datasheet

Description :

1. Silm SIL4-pin Package

2. Extremely low on-resistance

3. Control low-level signal

Features :
1. A voltage-sensitive power PhotoMOS Conventional power PhotoMOS are connected externally to an input limiting resistor in order to obtain the appropriate LED current. Adding an internal constantcurrent element renders the input limiting resistor unnecessary, making it possible
for the PhotoMOS to be voltage-driven.

Datasheet PDF Download :
AQZ202D pdf

Others datasheet of same file : AQZ104, AQZ104D, AQZ105, AQZ105D, AQZ107
