Part Number : NAS6203, (NAS6203 - NAS6220)
Function : Alloy Steel Short Thread
Maker : AIA ( Aerospace Industries Association ) , NAS
Pinouts :
Description :
National Aerospace Standard
|
Basic Number |
ØN |
ØP |
R RAD |
(T) |
ØTD |
U |
W |
X |
Y |
Inspection Data |
||||
|
MAX |
MIN |
MAX |
MIN |
AA |
BB |
CC |
||||||||
|
NAS6203 |
.19 |
.075 |
.020 |
.010 |
.323 |
.1840 |
.1810 |
.039 |
.410 |
.156 |
.094 | .0045 | .0040 | .005 |
|
NAS6204 |
.25 |
.081 |
.020 |
.010 |
.370 |
.2440 |
.2410 |
.045 |
.480 |
.179 |
.107 | .0045 | .0030 | .006 |
|
NAS6205 |
.31 |
.081 |
.020 |
.010 |
.438 |
.3060 |
.3020 |
.052 |
.552 |
.208 |
.125 | .0045 | .0030 | .008 |
|
NAS6206 |
.38 |
.111 |
.025 |
.015 |
.454 |
.3680 |
.3640 |
.052 |
.623 |
.208 |
.125 | .0045 | .0025 | .009 |
|
NAS6207 |
.44 |
.111 |
.025 |
.015 |
.528 |
.4310 |
.4260 |
.062 |
.764 |
.250 |
.150 | .0060 | .0025 | .010 |
|
NAS6208 |
.50 |
.111 |
.030 |
.020 |
.528 |
.4930 |
.4880 |
.062 |
.836 |
.250 |
.150 | .0060 | .0020 | .011 |
|
NAS6209 |
.56 |
.146 |
.035 |
.020 |
.594 |
.5550 |
.5500 |
.068 |
.978 |
.278 |
.167 | .0060 | .0020 | .012 |
|
NAS6210 |
.62 |
.146 |
.040 |
.025 |
.626 |
.6180 |
.6120 |
.068 |
1.050 |
.278 |
.167 | .0060 | .0020 | .015 |
