Part Number : MJE13007F
Function : 400V, 8A, TRIPLE DIFFUSED NPN TRANSISTOR
Package : TO-220IS type
Maker : KEC
Pinouts :
Description :
1. Excellent Switching Times : ton=1.6ỌS(Max.), tf=0.7ỌS(Max.), at IC=5A
2. High Collector Voltage : VCBO=700V.
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 700 V
2. Collector to Emitter Voltage : Vceo = 400 V
3. Emitter to Base Voltage : Vebo = 9 V
4. Collector Current : Ic = 8 A
5. Total Dissipation : Pc = 40 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file : E13007F, E13007F2, MJE13007
