Part Number : K1338

Function : 900V, 2A, MOSFET, Transistor

Package : TO-220AB Type

Maker : Hitachi , Renesas Electronics

Pinouts :
K1338 datasheet

Description :

Silicon N-Channel MOSFET

Features :

•  Low on-resistance

•  High speed switching

•  Low drive current

•  No secondary breakdown

•  Suitable for switching regulator and DC-DC converter

Absolute Maximum Ratings (Ta = 25°C)

1. Drain to source voltage : VDSS = 900 V

2. Gate to source voltage : VGSS = ± 30 V

3. Drain current : ID = 2 A

4. Channel dissipation : Pch = 50 W

5. Channel temperature : Tch =  150 °C

6. Storage temperature : Tstg = -55 to +150 °C



Application :

1. High speed power switching


Datasheet PDF Download :
K1338 pdf

Others datasheet of same file : 2SK1338





PDF Download
