Part Number : K1166
Function : 500V, N-Ch, MOSFET
Package : TO-3P Type
Maker : Renesas Electronics
Pinouts :
Description :
Silicon N Channel MOSFET
Features :
• Low on-resistance
• High speed switching
• Low drive current
• No secondary breakdown
• Suitable for switching regulator and DC-DC converter
Absolute Maximum Ratings (Ta = 25°C)
1. Drain to source voltage : VDSS = 500 V
2. Gate to source voltage : VGSS = ± 30 V
3. Drain current : ID = 12 A
4. Channel dissipation : Pch = 100 W
5. Channel temperature : Tch = 150 °C
6. Storage temperature : Tstg = -55 to +150 °C
Datasheet PDF Download :
Others datasheet of same file :
2SK1165, 2SK1166, K1165
