Part Number : C3150
Function : NPN Silicon Power Transistors / 800 Volts, 50 Watts, 3 Ampere
Package : TO-220 Type
Maker : Mospec Semiconductor
Pinouts :
Description :
The C3150 designed for use in high-voltage, high-speed, power switching applications such as switching regulator's, inverter, and converter.
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 900 V
2. Collector to Emitter Voltage : Vceo = 800 V
3. Emitter to Base Voltage : Vebo = 7 V
4. Collector Current : Ic = 3 A
5. Total Dissipation : Pd = 50 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file : 2SC3150
