Part Number : B1392
Function : 70V, 4A, Silicon PNP Triple Diffused Transistor
Package : TO-220FM Type
Maker : Hitachi , Renesas Electronics
Pinouts :
Description :
Application : Low frequency power amplifier
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = - 70 V
2. Collector to Emitter Voltage : Vceo = - 60 V
3. Emitter to Base Voltage : Vebo = - 5 V
4. Collector Current : Ic = - 4 A
5. Total Dissipation : Pc = 2 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file : 2SB1392
