Part Number : A1626
Function : - 400V, PNP Silicon Transistor
Maker : NEC , Renesas Technology
Pinouts :
Description :
The A1626 is designed for general purpose amplifier and high speed switching applications.
Features :
1. High Voltage.
2. High Speed Switching.
3. Low Collector Saturation Voltage.
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = - 400 V
2. Collector to Emitter Voltage : Vceo = - 400 V
3. Emitter to Base Voltage : Vebo = - 7 V
4. Collector Current : Ic = - 2 A
5. Total Dissipation : Pc = 1 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file : 2SA1626
