Part Number : 2SK3141
Function : 30V, 75A, MOSFET, Transistor
Package : TO-220AB Type
Maker : Renesas Electronics
Pinouts :
Description :
Silicon N Channel MOSFET
Features :
• Low on-resistance RDS(on)= 4 mΩtyp.
• Low drive current
• 4 V gate drive device can be driven from 5 V source
Absolute Maximum Ratings (Ta = 25°C)
1. Drain to source voltage : VDSS = 30 V
2. Gate to source voltage : VGSS = ± 20 V
3. Drain current : ID = 75 A
4. Channel dissipation : Pch = 100 W
7. Avalanche energy : Ear = 122 mJ
8. Channel temperature : Tch = 150 °C
9. Storage temperature : Tstg = -55 to +150 °C
Applications :
High Speed Power Switching
Datasheet PDF Download :
Others datasheet of same file : K3141
