Part Number : TSA1001
Function : 10-BIT, 25MSPS, 35mW, A/D CONVERTER
Package : TQFP48 Type
Maker : STMicroelectronics
Pinouts :
Description :
The TSA1001 is a 10-bit, 25Msps sampling frequency Analog to Digital converter using a CMOS technology combining high performances and very low power consumption.
The TSA1001 is based on a pipeline structure and digital error correction to provide excellent static linearity and achieve 9.7 effective bits at Fs=25Msps, and Fin=5MHz.
Especially designed for portable applications, the TSA1001 only dissipates 35mW at 25Msps. When running at lower sampling frequencies, even lower consumption can be achieved.
1. 10-bit A/D converter in deep submicron CMOS technology
2. Ultra low power consumption: 35mW @ 25Msps (10mW @ 5Msps)
3. Single supply voltage: 2.5V
4. Input range: 2Vpp differential
5. 25Msps sampling frequency
