Part Number : PN2907A
Function : 60V, PNP General-Purpose Translator
Package : TO-92, SOT23, SOT-223 Type
Maker : Fairchild Semiconductor
Pinouts :
Description :
The 2907A, PN2907A, MMBT2907A, and PZT2907A are 60V PNP bipolar transistors designed for use as a general purpose amplifier or switch in allications that require up to 500mA.
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 60 V
2. Collector to Emitter Voltage : Vceo = 60 V
3. Emitter to Base Voltage : Vebo = 5 V
4. Collector Current : Ic = 800 mA
5. Junction Temperature : Tj = 150°C
6. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file :
2907A, MMBT2907A, MMBT2907A_D87Z, PN2907, PN2907ABU
