Part Number : ES2A
Function : 2.0A, 50V, Super-fast rectifier
Package : Surface mount
Maker : Diodes Incorporated.
Pinouts :
Description :
• Glass Passivated Die Construction
• Super-Fast Recovery Time For High Efficiency
• Surge Overload Rating to 50A Peak
• Ideally Suited for Automated Assembly
• Lead Free Finish/RoHS Compliant (Note 1)
Mechanical Data
• Case: SMA/SMB
• Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020
• Terminals: Lead Free Plating (Matte Tin Finish). Solderable per MIL-STD-202, Method 208
• Polarity: Cathode Band or Cathode Notch
• SMA Weight: 0.064 grams (approximate)
• SMB Weight: 0.093 grams (approximate)
Others datasheet of same file : ES2A/A, ES2B/A, ES2C/A, ES2D/A
Datasheet PDF Download :
