Part Number : 2SK2221
Function : 200V, 8A, MOSFET, Transistor
Package : TO-3P type
Maker : Renesas Electronics
Pinouts :
Description :
Silicon N-Channel MOSFET
Features :
• High power gain
• Excellent frequency response
• High speed switching
• Wide area of safe operation
• Enhancement–mode
• Good complementary characteristics
• Equipped with gate protection diodes
Absolute Maximum Ratings (Ta = 25°C)
1. Drain to source voltage : VDSS = 200 V
2. Gate to source voltage : VGSS = ± 20 V
3. Drain current : ID = 8 A
4. Channel dissipation : Pch = 100 W
5. Channel temperature : Tch = 150 °C
6. Storage temperature : Tstg = -55 to +150 °C
Application :
1. Low frequency power amplifier
2. Complementary pair with 2SJ351, 2SJ352
Datasheet PDF Download :
Others datasheet of same file : K2221
