Part Number : 2SC5508
Marking : T79
Function : 3.3V, 35mA, NPN Transistor
Package : Flat-Lead 4-Pin Thin-Type Super Minimold Type
Maker : Renesas Electronics
Pinouts :
Description :
NPN SILICON RF TRANSISTOR
Features
1. FLAT-LEAD 4-PIN THIN-TYPE SUPER MINIMOLD (M04)
2. Ideal for low-noise, high-gain amplification applications
3. Flat-lead 4-pin thin-type super minimold (M04) package
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 15 V
2. Collector to Emitter Voltage : Vceo = 3.3 V
3. Emitter to Base Voltage : Vebo = 1.5 V
4. Collector Current : Ic = 35 mA
5. Total Dissipation : Pc = 115 mW
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file :
C5508, 2SC5508-A, 2SC5508-T2, 2SC5508-T2-A, 2SC5508-T2B
