Part Number : 2SC4942
Function : NPN SILICON TRIPLE DIFFUSED TRANSISTOR
Maker : NEC
Pinouts :
Description :
The 2SC4942 is a transistor developed for high-speed high voltage switching.
This transistor is ideal for use in switching devices such as switching regulators and DC/DC converters.
Features :
• New package with dimensions in between those of small signal and power signal package
• High voltage
• Fast switching speed
• Complementary transistor with the 2SA1871
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 600 V
2. Collector to Emitter Voltage : Vceo = 600 V
3. Emitter to Base Voltage : Vebo = 7 V
4. Collector Current : Ic = 1 A
5. Total Dissipation : Pc = 2 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
