Part Number : 2N2222
Function : NPN General Purpose Amplifier
Package : TO-92 Type
Maker : Fairchild Semiconductor
Pinouts :
Description :
This device is for use as a medium power amplifier and switch requiring collector currents up to 500mA. Switch requiring collector currents up to 500mA.
1. TO-92 : PN2222A
2. SOT-23 : MMBT2222A
3. SOT-223 : PZT2222A
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 40 V
2. Collector to Emitter Voltage : Vceo = 75 V
3. Emitter to Base Voltage : Vebo = 6 V
4. Collector Current : Ic = 1A
5. Storage Temperatue : Tsg = -55 ~ +150°C
Datasheet PDF Download :
Others datasheet of same file :
MMBT2222A, PN2222A, PN2222ABU, PZT2222A
