Microchip
2N3440
Power Bipolar Transistor, 1A I(C), 250V V(BR)CEO, 1-Element, NPN, Silicon, TO-205AD, Metal, 3 Pin

PDF Datasheet
DistributorStock110100Link
Onlinecomponents.com2113.39Visit Site
RS (Formerly Allied Electronics)20.890.82Visit Site
DigiKey17013.1912.2501Visit Site
Master Electronics2113.39Visit Site
NAC Semi13812.56Visit Site
Microchip17313.19Visit Site
Easev2,6664.524174.2979615Visit Site
    Powered by Octopart

Description

:

These devices are particularly suited as drivers in high-voltage low current inverters, switching and series regulators.

Features :


1. DUAL SILICON PLANAR EPITAXIAL NPN TRANSISTOR

2. HIGH VOLTAGE



Absolute maximum ratings ( Ta=25°C )

1. Collector to Base Voltage : Vcbo = 300 V
2. Collector to Emitter Voltage : Vceo = 250 V
3. Emitter to Base Voltage : Vebo = 7 V
4. Collector Current : Ic = 1 A
5. Total Dissipation : Pc = 5 W
6. Junction Temperature : Tj = 200°C
7. Storage Temperatue : Tsg = -65 ~ +200°C
