Part Number : 2SD882
Function : NPN medium power transistor
Package : SOT-32 / TO-126
Maker : STMicroelectronics
Pinouts :
Description :
The device is a NPN transistor manufactured by using planar technology resulting in rugged high performance devices. The complementary PNP type is 2SB772.
Features :
1. High current
2. Low saturation voltage
3. Complement to 2SB772
Absolute maximum ratings ( Ta=25°C )
1. Collector to Base Voltage : Vcbo = 60 V
2. Collector to Emitter Voltage : Vceo = 30 V
3. Emitter to Base Voltage : Vebo = 5 V
4. Collector Current : Ic = 3 A
5. Total Dissipation : Pc = 12.5 W
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -65 ~ +150°C
Applications
1. Voltage regulation
2. Relay driver
3. Generic switch
4. Audio power amplifier
5. DC-DC converter
Others datasheet of same file : D882
