Part Number : TPS2546
Function : USB Charging Port Controller and Power Switch with Load Detection / Available in 16-Pin QFN (3x3) Package
Maker : Texas Instruments

Pinouts :
TPS2546 datasheet

Description :

The TPS2546 is a USB charging port controller and power switch with an integrated USB 2.0 high-speed data line (D+/D–) switch. TPS2546 provides the electrical signatures on D+/D– to support charging schemes listed under device feature section.

TI tests charging of popular mobile phones, tablets and media devices with the TPS2546 to ensure compatibility with both BC1.2 compliant and non-BC1.2 compliant devices.




Datasheet PDF Download :
TPS2546 pdf

Others datasheet of same file : 2546,TPS2546,TPS2546RTER,TPS2546RTET
