Part Number : TA7317P
Function : PROTECTION CIRCUIT FOR OCL POWER AMPLIFIER AND SPEAKER / SIP 9PIN
Maker : Toshiba

Pinouts :
TA7317P datasheet

Description :





* Over current detecting circuit
   - Operation at the time of over load, such as a speaker terminal short.

* DC voltage detecting circuit
  - Operation at the time when positive or negative DC voltage (+- 1.1V of detection level) has generated at output terminals.

* Muting circuit
  - Transient noise protection when power is ON-OFF.

* Relay driver circuit (Drive current of 130mA at Max.)

* Operation by dual power supply.




Datasheet PDF Download :
TA7317P pdf

Others datasheet of same file : TA7317P
