Part Number : STK4142II

Function : AF Power Amplifier (Split Power Supply) (25W + 25W min, THD = 0.4%)

Maker : SANYO -> Panasonic

Pinouts :
STK4142II datasheet

Description :

*  The STK4102II series (STK4142II) and STK4101V series (high-grade type) are pin-compatible in the output range of 6W to 50W and enable easy design.

* Small-sized package whose pin assignment is the same as that of the STK4101II series

* Built-in muting circuit to cut off various kinds of pop noise

* Greatly reduced heat sink due to substrate temperature
125°C guaranteed

* Excellent cost performance


Datasheet PDF Download :
STK4142II pdf

Others datasheet of same file : STK4142,STK4142II
