Part Number : LMH2120
Function : LMH2120 6 GHz Linear RMS Power Detector with 40 dB Dynamic Range / a tiny 6-bump DSBGA package.
Maker : Texas Instruments

Pinouts :
LMH2120 datasheet

Description :

The LMH2120 is a 40 dB Linear RMS power detector particularly suited for accurate power measurement of modulated RF signals that exhibit large peak-to-average ratios, i.e, large variations of the signal envelope. Such signals are encountered in W-CDMA and LTE cell phones. The RMS measurement topology inherently ensures a modulation insensitive measurement.




Datasheet PDF Download :
LMH2120 pdf

Others datasheet of same file : LMH2120,LMH2120UM,LMH2120UM/NOPB,LMH2120UMX,LMH2120UMX/NOPB
