Part Number : LM323

Function : THREE-TERMINAL 3A-5V POSITIVE VOLTAGE REGULATORS

Maker : STMicroelectronics

Pinouts :
LM323 datasheet

Description :

The LM323 are three-terminal positive voltage regulators with a preset 5 V output and a load driving capability of 3 A. New circuit design and processing techniques are used to provide the high output current without sacrificing the regulation characteristics of lower current devices.



The 3 A regulator is virtually blowout proof.

• Output current: 3 A
• Internal current and thermal limiting
• Typical output impedance: 0.01 Ω
• Minimum input voltage: 7.5 V
• Power dissipation: 30 W




Datasheet PDF Download :
LM323 pdf

Others datasheet of same file : LM323, LM323T
