Part Number : 7805
Function : UA7800 Series / POSITIVE-VOLTAGE REGULATORS
Maker : Texas Instruments

Pinouts :
7805 datasheet

Description :

This series of fixed-voltage integrated-circuit voltage regulators is designed for a wide range of applications. These applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. Each of these regulators can deliver up to 1.5 A of output current. The internal current-limiting and thermal-shutdown features of these regulators essentially make them immune to overload.

In addition to use as fixed-voltage regulators, these devices can be used with external components to obtain adjustable output voltages and currents, and also can be used as the power-pass element in precision regulators.


Datasheet PDF Download :
7805 pdf

Others datasheet of same file : 7805,7805CKC,7805CKCS,7805CKTER,7808CKC
