Part Number : 24C64
Function : 64/32 Kbit Serial IC Bus EEPROM
Maker : Fairchild Semiconductor

Pinouts :
24C64 datasheet

Description :

FM24C64 is a 64Kbit CMOS non-volatile serial EEPROM organized as 8K x 8 bit memory. This device confirms to Extended IIC 2-wire protocol that allows accessing of memory in excess of 16Kbit on an IIC bus.

This serial communication protocol uses a Clock signal (SCL) and a Data signal (SDA) to synchronously clock data between a master (e.g. a microcontroller) and a slave (EEPROM). FM24C64 is designed to minimize pin count and simplify PC board layout requirements.


Datasheet PDF Download :
24C64 pdf

Others datasheet of same file : 24C64,FM24C64,FM24C64E,FM24C64L,FM24C64LZ
