Part Number : 1N4751
Function : 30V, 1W, Zener Diode, Rectifier
Package : DO-41 Type
Maker : Fairchild Semiconductor
Pinouts :
Description :
Tolerance = 5%
Absolute maximum ratings ( Ta=25°C )
1. Power Dissipation : Pd = 1 W
2. Derate above 50°C : Pd = 6.67 mW/°C
3. Junction Temperature : Tj = - 65 ~ + 250°C
4. Storage Temperatue : Tsg = - 65 ~ +200°C
Datasheet PDF Download :
Others datasheet of same file : 1N4728, 1N4728A, 1N4729, 1N4729A, 1N4730, IN4751
